MTi15 160 x 120px Thermal Imager

Brand: Major TECH
Product Code: ELMTi15

Price: $4,455.00
Ex Tax: $4,050.00

- +

The MT329 from Major TECH is a handheld multifunction tester that combines Insulation and Continuity testing, Resistance, Loop Impedance, RCD, Voltage, and Phase Sequence tests in one device.

The Loop Impedance test offers two methods: a high-current test up to 18.3A and a ZL-PE RCD range test that ensures RCDs rated above 30mA do not trip during the test. The MT329 features several RCD test functions, including Auto Test, Residual Current Test with various current settings, and RCD Test Time. The insulation test function operates at 250V, 500V, and 1000V, measuring insulation resistance up to 4000MΩ with automatic discharge after testing.

It also provides Low Ohm Resistance measurements. Additional functions include AC and DC voltage measurement, an AC+DC auto-mode, Data Hold, and auto power-off. The large backlit multi-LCD displays simultaneous measurements, ensuring clear visibility. With a CAT III 600V and CAT IV 300V rating, the MT329 provides a high level of safety. The meter also features Bluetooth communication and internal memory for data storage and transfer. The Bluetooth app, compatible with both Android and iOS, enhances versatility, making the MT329 suitable for troubleshooting and preventative maintenance tasks for electricians.



Features of the MTi15 160 x 120px Thermal Imager

  • 160 x 120 Pixel Thermal Detector
  • 19,200 points real temperature
  • 50Hz Image Frequency
  • 3 Area and 2 Line Analysis
  • 3 Manual Spots
  • Hot, Cold and Centre Spot Temperature
  • 3.5” TFT LCD display, Touch Screen
  • Instant share & save via WiFi to PC, iOS and Android smart devices
  • Colour Palettes include Iron, Rainbow, Grey, Grey Inverted, Brown, Blue/ Red, Feather, Zone Alarm
  • Rugged and industrial design casing
  • Easy to use functions via touch screen

Specifications of the MTi15 160 x 120px Thermal Imager

Imaging and Optical Data

 Function  Range
 Field of View 20.7° x 15.6°
 Spatial Resolution (IFOV) 1.88mrad
 Thermal Sensitivity/NETD <0.05° at 30°C (86°F)/50mK
 Image Frequency 50Hz
 Focus Mode Manual
 Zoom 16x Digital Zoom
 Focal Length 7.5mm
 Focal Plane Array (FPA) / Spectral Range Uncooled microbolometer / 8-14μm
 IR Resolution 160 x 120 pixels




Image Presentation

 Insulation
 Display 3.5" TFT LCD, Touch Screen
 Image Modes IR Image, Visual Image, Pic-in-Pic, Auto Fusion
 Picture in Picture IR area on visual image or visual image on IR
 Colour Palettes Iron, Rainbow, Grey, Grey Inverted, Brown, Blue-Red, Feather, Zone Alarm




Measurement

 Loop Impedance
 Temperature Range -20°C to 150°C (-4°F to 302°F) / 0°C to 650°C (32°F to 1202°F)
 Temperature Accuracy +2°C (3.6°F) or ±2% of reading




Measurement Analysis

 Loop Impedance
 Spot Centre Spot & 3 Manual Spots
 Line 2 Line Analysis
 Area 3 Area Analysis
 Automatic Auto Hot & Cold Markers
 Adjustable Emissivity  0.01 to 1.0
 Measurement Corrections Emissivity, Reflected Temperature




Storage

 Loop Impedance
 Video 8GB Micro SD Card, 3.4GB Internal EMMC
 Video Storage Mode Standard MPEG-4
 Image Storage Mode Bitmap (.bmp) and simultaneous visual image including measurement data




Digital Camera

 Loop Impedance
 Built-in 2 Megapixels
 Built-in Digital Lens Data FOV 65°




Data Communication Interfaces

 Loop Impedance
 USB Type C, Data and Live Video transfer to PC
 Wi-Fi 802.11 Data and Live Video transfer to App
  Weight 500g
 Dimensions 224 x 77 x 96mm
 Warranty 2 Years




Accessories for the MT329 Bluetooth Handheld Multifunction Tester

  • Carrying Case
  • LI-ion Battery
  • Instruction Manual
  • Charger
  • USB cable
